Product Features

Multifactor Options: Iris & Face Fusion, Pinpad, Card Reader

Operates in Iris only, Face only, Iris and/or Face, Iris-Face fusion mode.

Simultaneous Biometric Capture

Automatically captures dual irises and face simultaneously at the same distance.

Presentation Attack Detection (PAD)

A proven set of anti-spoof measures that continue to set the standard for the industry is included.

Non-Contact & Easy Authentication

Automatically captures faces and irises up to 24 inches (60cm).

Intuitive User Feedback LCD

A new circular LCD built into the optical system provides user guidance for fast authentication.

Standards Compliant

IEC 62471:2006, UL 294, CE, FCC, KC, ROHS, UKCA

Accommodates All User Heights

The optical system automatically adjusts for user heights and is ADA 508 compliant.

Advanced Security

Supports comprehensive data encryption, advanced network security, and secure boot.

Enhanced Capture Range

Wide recognition range of Iris 30 – 60cm (12 – 24″) & Face 30 – 80cm (12 – 32″)

Technical Specifications

Dimensions (W x H x D)	188mm x 199mm x 34mm (7.4” x 7.8” x 1.3”)
Weight	810g (1.8lb)
Type	Walk-up
Power Input	24VDC or PoE+
Display Touchscreen	Main Display: 7” LCD, Selﬁe Display: 39mm (1.54“) circular LCD
User Interface	Auto-tilt, Self-guidance with visual displayed
Operation	All combinations of Iris, Face, Iris & Face Fusion, Pin, Card
User Capacity	Up to 100,000 users on device
Transactions	Up to 1,000,000 on device (up to 100,000 with audit face images)
Encryption	AES-256
Platform Security	Secure Boot, Root of Trust
Matching Speed	Less than 1 second
Languages	Supports multiple languages/characters simultaneously
Iris Camera	ISO 29794-6 Compliant

Face Camera	ISO 29794-5 Compliant
Operating Range	Iris Camera: (30 – 60cm (12 – 24”) / Face Camera: 30 – 80cm (12 – 32“ )
Tilt	Auto tilt, -30° – +30°
Algorithms	Iris recognition, Face recognition, Iris/Face PAD, Lens detection, Face mask detection
Real Time Clock	Rechargeable battery
Connectivity	ToF Sensor
Card Reader (optional)	Prox (125kHz) and iCLASS®, Seos®, MIFARE®/DESFire® (13.56MHz) card supported
Relay	2-Dry contact outputs available
Wiegand	Wiegand In/Out (ﬂexible up to 200bits and pass through to the access panels)
PoE+	IEEE802.3at compliant, 30 watts
Serial	RS232, RS485(OSDP), RS422
Indicator	Multi-color LED for power and user guidance from 7” LCD
Certifications	FCC, CE, KC, UKCA, UL294, ISTA, Eye Safety
Temperature	Operating: 0°C – 45°C (32°F – 113°F) / Storage: -20°C – 90°C (-4°F – 194°F)
